547 Big Block Ford Pump Gas Engine
Ford Pump Gas Engines

547 Big Block Ford Pump Gas Engine $22,150

547/765HP $22,150
Less Carb & Ignition

Sorry, This Ain't The Engine Out Of Your Daddy's Lincoln. No Sir, This BBF Is Packed With All The Latest Go Fast Parts That You Could Ever Wish For. Eliminator Products Block, Lunati Crank, Molnar Rods, JE Pistons And AFR 315 Bullitt 14° Heads. Add The Magic Machine Work And Assembly At Shafiroff Racing And You Have A Proven Winner Here. Toss In A Comp Cams Custom Hydraulic Roller Cam With High Rev Lifters And You Have A True Street Masterpiece! Available With Canton Oil Pans To Fit Almost All Ford Car And Truck Chassis.

Now, It's Not Just The Chevy Boys Who Can Have "Big Block Power" In Their Street Toys. Giddy-Up Boys And Girls!

  • Horsepower
  • Torque
  • Bore & Stroke
  • Compression Ratio
  • Fuel Requirement
  • 765 @ 6000 RPM
  • 735 @ 4900 RPM
  • 4.500 x 4.300
  • 10.75 to 1
  • 92 Octane

  • Eliminator Products Street/Race 10.320" Block w/Splayed 4 Bolt Main Caps
  • Lunati 4340 4.300" Forged Steel Crank
  • Molnar 4340 H-Beam Rods w/ARP 2000 Asymmetrical Bolts
  • Clevite 77 "H" Series Main & Rod Bearings
  • Custom JE 10.75-1 2618 Forged Aluminum Pistons
  • Plasma Moly 1.5/1.5/3.0mm Ring Set
  • SSRE/Comp Cams Hydraulic "Street Roller" Camshaft
  • High Performance Hi-Rev Hydraulic Roller Lifters
  • Rollmaster Billet Timing Set w/IWIS Chain & Torrington Bearing
  • AFR Bullitt 14° 315cc Fully CNC Ported Aluminum Heads
  • 2.300"/1.760" Bead Lock Stainless Valves
  • Pac Racing Hydraulic Roller Springs w/10° Steel Retainers
  • ARP High Performance 9/16" Head Bolts
  • Comp Cams Ultra Pro Magnum Roller Rockers
  • Chromemoly (1) Piece .080" 3/8" Wall Pushrods
  • FelPro HP Head Gaskets w/Pre-Flattened Steel Wire
  • AFR Bullitt Dominator Aluminum Intake (1)
  • Canton Road Race Series Oil Pan w/Windage Tray (2)
  • Melling HP Oil Pump w/Canton Pickup
  • OEM Style Front Cover w/Billet Timing Pointer
  • High Performance Harmonic Balancer
  • Complete Assembly Internally Balanced (3)
  • Individually Dyno Tested & Tuned
  • Actual Dyno Sheet Provided
  • Footnotes:
  • (1) 4150 Style Intake Available.
  • (2) Specify Front or Rear Sump at time of order.
  • (3) Neutral Balance Flexplate/Flywheel Required.
Shafiroff Racing Engine Upgrade Packages
Holley Sniper EFI
Holley Sniper II EFI Package$2995
Includes: Holley Super Sniper EFI Unit, Sniper EFI Touchscreen LCD Programmer, Bosch LSU 4.9 Wideband Oxygen Sensor, Stainless Steel Clamp-On Oxygen Sensor Installation Kit (May Also Be Welded), Hyperspark Distributor and SSRE Custom Ignition Wires w/Looms. Base Tuneup and Parameters Set and Calibrated on Your Engine.
Igniton Components
Hyperspark Ignition Coil $39
Shafiroff Racing Engine Options
Fuel System Components
Why Buy A Carburetor From Us?

Yes, you can certainly purchase a stock carb from the big mail order companies but we've seen carbs out of the box down on power as much as 40HP and between 15-20HP is common. That's why we disassemble and blueprint EVERY carburetor before we ever bolt it on your engine. We then tune, adjust and jet your carb on your engine so you get every ounce of power that you paid for.

Even if you're considering one of our Engine Kits or simply looking for a replacement carb, the same blueprint work is done and we dyno test it on a comparable engine to yours before it ships!
 $Priceless
APD 950 CFM 4150 Series Carb Package includes: 2 Circuit Billet Carb, Phenolic Spacer, Aluminum AN Fuel Fittings, Studs & Gaskets. Dyno Tuned, Jetted and Calibrated on your engine.ImageShafiroff Racing Available Options Close$995
APD 1040 CFM 4150 Series Carb Package includes: 2 Circuit Billet Carb, Phenolic Spacer, Aluminum AN Fuel Fittings, Studs & Gaskets. Dyno Tuned, Jetted and Calibrated on your engine.ImageShafiroff Racing Available Options Close$995
APD 1050 CFM 4500 Series Carb Package includes: 2 Circuit Billet Carb, Phenolic Spacer, Aluminum AN Fuel Fittings, Studs & Gaskets. Dyno Tuned, Jetted and Calibrated on your engine.ImageShafiroff Racing Available Options Close$1395
Mechanical Fuel Pump Package Includes: High Volume Race Design 6 Valve Pump, Braided Fuel Line Inlet Kit w/8AN Lines and Fittings. Plumbed, Installed & Dyno Tested On Your Engine. $395
Igniton Components
MSD Electronic Ignition Package includes MSD Pro Billet Distributor, Steel Distributor Gear, Custom Moroso Wire Set and Loom Kit. Dyno Tested and Calibrated on your engine. $695
MSD 6AL Digital Electronic Ignition Box w/Hi-Speed Rev Limiter $305
MSD 6AL-2 Digital Electronic Ignition Box w/Launch Control & Hi-Speed Rev Limiter $480
MSD Blaster 3 Hi Performance Ignition Coil w/HEI Style Post $65
MSD 8201 Pro Power Coil $159
Pistons - Pins - Rings - Bearings
Total Seal TNT "Hellfire" Rings $175
Oil Pumps - Oil Pans - Vacuum Pump
Lokar Custom Locking & Calibrated Dipstick (Upgrade)ImageShafiroff Racing Available Options Close$95
Additional Parts - Labor - Accessories
Cometic MLS (Multi Layered Steel) Head Gaskets $125
SFI Approved Harmonic Balancer (Required At All Race Tracks) $150
Master Power Silent Drive Vacuum Pump Kit For Power BrakesImageShafiroff Racing Available Options Close$625
ATI SFI Flexplate - Internally Balanced 157 Tooth 10.5" Bolt Pattern $275
ATI SFI Flexplate - Internally Balanced 164 Tooth 11.5" Bolt Pattern $275
Steel Billet Flywheel - Internally Balanced 157 Tooth 10.5" Bolt Pattern $350
Steel Billet Flywheel - Internally Balanced 164 Tooth 11.5" Bolt Pattern $350
PowerMaster 9603 Hi-Torque Mini Starter. Fits 4.084" block plate with 3/4" depth ring gear. $229
Edelbrock Aluminum "High Volume" Mechanical Water Pump. Clockwise Rotation w/Left Hand Inlet. Natural Finish. Installed With ARP Stainless Steel Hardware. $295
Billet Specialties Tru Trac Serpentine SystemImageShafiroff Racing Available Options Close$Call
Custom Powder Coating Packages Available $Call
